Thursday, August 22, 2019

Magnifier for Skin Treatment


There is an unknown model of circular magnifier there at the left side of the photo. It seems to be a "stand-alone" or with foot as i cannot see a clamp or table stand

---
notes:

photos taken from Ms. Arra San Agustin Instagram account

https://www.instagram.com/p/BqrisJOgbSJ/

skin treat @facesandcurves_ph

Saturday, April 27, 2019

Zoom Stereo Microscope AMZ ZM-2BD1

AMZ ZM-2BD1 0.7-4.5X Zoom Stereo Microscope







1. Excellent Image Quality & Optical Performance with Optical System.
2. Comfortable Operation with Ergonomic Design Principle.
3. A Wide Range of Accessories to be Equipped with the Microscope for Multi-purposeIt is an Outstanding
4. Assistant in Industrial, Medical and Scientific Research Areas

Model: ZM-2BD1
1.View head 45 degree inclined Pupillary adjust distance:55-75mm
2. Zoom ratio:1:6.4
3. Eyepiece:WF10x/20mm
4. Zoom objective:0.7x-4.5x
5. Magnification:7x-45x,  auxiliary objective can make magnification to 3.5x-180x
6.working distance:105mm
7.pillar stand height: 245mm
8.base size: 210mm x 260mm x 45mm

EyepiecesStandardAuxiliary lens 0.5XAuxiliary lens 1.5X
Working distance 100mmWorking distance 165mmWorking distance 45mm
Magnification view fieldField of viewMagnification view fieldField of viewMagnification view fieldField of video
10X/20mm7.0X28.6mm3.5X57.1mm10.5X19mm
45.0X4.4mm22.5X8.9mm67.5X3mm
15X/15mm10.5X21.1mm5.25X42.8mm15.75X14.3mm
67.5X3.3mm33.75X6.7mm101.25X2.2mm
20X/10mm14.0X14.3mm7.0X28.6mm21.0X9.5mm
90.0X2.2mm45.0X4.4mm135.0X1.5mm


Accessories:
Eyepieces: WF10X/20mm, WF15X/15mm, WF20X/10mm
Auxiliary lens: 0.5X/165mm. 1.5X/45mm. 2X/30mm.
Light sources: LED ring light, cold light illumination

Tuesday, February 19, 2019

ZTX-10 Stereo Microscope


Stereo Microscope
Waterun ZTX-10









Information
1. Sharp stereo erect image over a vide field view.
2.45° inclined and 360° rational binocular head with locked-in eyepiece. The left ocular-tube with diopter adjustment ±5dp,The interpupillary distance is between 55-75mm
3.Three kinds of 90° rotational objective ion:1x/2x,1x/3x,2x/4x.
4. ZTX-10/ZTX-20 series supplied with pillar style stand, ZTX-10-W ZTX-20-W series supplied with arm curved style stand.
5. Electric apparatus has CE approval
6.Power supply 110V/60Hz or 220V/50Hz
7.Each set packed in Styrofoam and in an inner box. Four sets in one carton.
8. A wide range of optional accessories.

Optional accessories:
1.Eyepiece WF5x,WF10x,WF15x,WF20x
2.Auxiliary objective 0.5x,0.75x,1.5x,2x
3.Video Attachment for Microscope
4.Darkfield stage,Φ94.5mm
5.Jewel tweezers
6.White/black working plate,Φ95mm
7.Frosted glass working plate,Φ95mm

Microscope Fluorescent Ring Light 8W- white light

Microscope Fluorescent Ring Light

FL-8
(old code= MFFRL-8W)









Voltage: 110V or 220v
Power: 8W
Color temperature:  6500K or 2700K(110V)
Light adjust: No
Inner diameter(mm): 61mm
Packaging: Styrofoam Box and Strong Carton Box


===
notes:
1. Cross ref / old code = MFFRL-8W
2. fits Zoom7045
3. the PN of the replacement circular lamp is FL-8-CL



Monday, February 18, 2019

Microscope LED Ring Light LED-60T








LED-60T


The product has following advantages: less fever heat, light is soft , natural and non-strobe, colour with no distorted ,long life, energy saving, small and beautiful, installation is convenient. The power shell used new imported plastic injection molding and processing ,aging resistance, with fire retardant, lampshade anti-static treatment, The colour of shell can be according to client’s needs to set .


  • Adaptable to SFC-11, SMZ-140, SMZ-168 and K series
  • 3 fixing screws
  • 60 LED illumination
  • +/- 6800K color temperature(CE)
  • Maximum luminance 15.000 lux at 100mm working distance
  • Life time up to 25.000 hours
  • covers a working distance from 50 - 150mm
  • Dimensions, outer Ø 102mm, inner Ø 60mm, height 29mm

LED-60T Separate lighting available by 4-divided segments
◆Item mumber: LED-60T
◆Illuminance: 4W LED
◆Number of LED: 60PCS
◆Inner diameter(mm): 25-63mm (for stereo head microscopes)
External Diamerter: 100mm
◆Color temperature: 6500-7000 K
◆Brightness adjustment: Yes
◆Material: Metal &plastic
◆Power supply: 100V-240V
◆Working distance: 50-180 mm


===
notes:
1. fits  fits Zoom7045, YK-S64T



WF20X/10 Wide Field Stereo Microscope Eyepiece 20X








WF20X/10 Wide Field Stereo Microscope Eyepiece
 Suitable for triocular binocular stereo microscope Material: Optical glass + metal Magnification: 20X
Mounting size: 30mm
Suitable for triocular binocular stereo microscope
Material: Optical glass + metal
Magnification: 20X
Mounting size: 30mm
Quantity: 1pc
Weight: 92g / 3.2oz
